MOTOR TYPE: SUPRAMATIC / PROMATIC SERIES 4
Please Note: To transfer the code from one hand transmitter to another, the signal strength
needs to be very strong. This means the units need to be very close together and have good
battery power.
The procedure is more reliable if the receiving transmitter is on the left hand side, ideally in
direct contact with the sending / existing transmitter, with their tops level (see image below).
Section 1: Transferring the code from a BiSecur hand transmitter to a BiSecur hand transmitter
1.) Press and hold the button on your existing hand transmitter (which has the code you want to
transfer.) The LED will illuminate constantly then start to flash red and blue, keep the button pressed down until the code has been successfully transferred.
2.) Once the first hand transmitter has started to flash red and blue, press and hold the button on the hand transmitter which is to receive the code. The LED will flash blue slowly for a few seconds then flash quickly for a few seconds, and then stop with no illumination (on later edition transmitters, when receiving a code, the LED will show solid blue first for a couple of seconds before flashing blue) The code has now been transferred. You can continue this process to transfer the code to different
buttons.
Please note – series 4 operators
Series 4 operators will not activate with a cloned code until an additional process of coding the hand
transmitter into the head unit has been completed.
Please note – series 4 operators
Series 4 operators will not activate with a cloned code until an additional process of coding the hand transmitter into the head unit has been completed.
1.) Once the code has been transferred to a new transmitter, you will need to press and hold the coded button down whilst in range of the head unit.
2.) The display will first show a flashing ‘11’ on a Supramatic series 4 or the LED will flash red on a Promatic series 4.
3.) After a few seconds the hand transmitter will then start to flash red and blue. – The display on a Supramatic will then flash ‘11’ rapidly or the LED will flash red rapidly on a Promatic series 4.
4.) The hand transmitter should now activate the operator.
